Proceq Original
Schmidt Live 8000

Proceq has taken its industry-leading, Original Schmidt, rebound hammer to a new level of performance and ease-of-use. Transformed now into a digitally-capable tool.

Unrivalled for testing, reporting and analysis of concrete strength and uniformity. Its comprehensive digital capability and the proven durability of Original Schmidt hammers combine to give you the world’s most advanced R-value concrete test hammer.
Abbey Spares Ltd Proceq Original Schmidt Live

Proceq Original Schmidt Live8000
The world’s most advanced R-value concrete test hammer

A versatile tool

Original Schmidt Live works as a:

  • Digital hammer with digital reporting and data sharing (via a free, comprehensive Apple iOS app and Android Operating System)
  • Stand-alone analogue hammer (use it offline and download data to the app later)
  • It also comes as a model that works as a digital print console by wirelessly connecting to a Bluetooth printer and directly printing out test results.

    Original Schmidt Live: a comprehensive R-value hammer for the concrete and paper industries and geologists.

    Speed and flexibility

  • Prepare, test and share test results (to all major standards) via the app up to 80 percent quicker than with traditional hammers. That’s an incredible time saving!
  • Send the report directly from the app to your customers and have your colleagues view it instantly on the Schmidt Live web reporting tool.
  • Free up your staff to be more productive and get more satisfaction from a once-laborious task.
  • Prevent read-out, transcription, and human errors, and avoid losing hand-written measurements, as all data is stored instantly on a safe and secure cloud.
  • Comprehensive Apple iOS app for measuring, reporting and analysis
  • Web reporting tool for instant offsite data availability and synchronising
  • Light and strong fibre-reinforced shell
  • Powered by flight-safe AAA batteries
  • Dual displays: analogue and backlit digital
  • All mechanical components are Original Schmidt components to ensure standards compatibility and durability
  • Click on the PDF to download a copy
    Download PDF of Proceq Original Schmidt Live

    Technical Specifications:

  • Impact energy Type N 2.207 Nm (1.63 ft lbf)
  • Impact energy Type L 0.735 Nm (0.54 ft lbf)
  • Housing dimensions 61 x 84 x 275 mm / 2.4 x 3.3 x 10.8 in
  • Weight (N-hammer) 1090 g / 2.4 lb
  • Weight (L-hammer) 850 g / 1.9 lb
  • Memory 2,000 measurement series
  • Displays Analog & backlit digital (100 x 100 pixels, graphic)
  • Charger connection Micro-USB
  • Battery Standard AAA, alkaline or rechargeable
  • IP classification IP54
  • Applications:

  • Original Schmidt Live has multiple applications and is a favorite of the concrete and paper industries and in geology work.
  • Concrete: strength estimations, formwork removal and to complement core testing.
  • Paper: roll profiling in mills and converter plants.
  • Geology: strength testing, ageing, weathering (field and lab).
  • Standards:

  • USA: ASTM C805,
  • ACI 228.1R
  • Europe: EN12504-2, EN13791
  • China: JGJ-T23
  • Japan: JCSE-G504
  • ISO 1920-7
  • JIS A1155 Russia:
  • GOST 22690-2015
